Caravan Mains Water Not Working? How to Find and Fix the Problem

The Symptom

You arrive at a caravan park, connect the hose from the tap to your van's mains water inlet, turn the tap on — and nothing comes out of your taps inside.

The water pump works perfectly on tank water. The problem is only with the mains connection. You end up filling the tanks from the hose and running off the pump for the whole trip.

This is one of the most common caravan plumbing issues in Australia, and in most cases it comes down to one small component.

How Your Caravan's Mains Water System Works

Before diving into the fix, it helps to understand how the two water sources — tank and mains — work together.

Your caravan has two ways of getting water to the taps:

1. Tank water — The 12V water pump draws water from your onboard freshwater tank and pushes it through the plumbing to your taps. You turn the pump on with a switch inside the van.

1. Mains water — When you connect a hose to the external mains water inlet, the park's water pressure pushes water directly through your plumbing to the taps. The pump should be switched off when using mains water.

These two water paths join together inside the van's plumbing, but they are kept separate by non-return valves (also called check valves or one-way valves). These valves ensure:

• Mains water pressure does not push water backwards into your tank
• Your pump does not push tank water backwards out through the mains inlet

There is no electronic switching or logic. The whole system relies on these simple mechanical valves and water pressure to direct the flow correctly.

The Pressure Limiting Valve

Between the external mains inlet and your internal plumbing sits a pressure limiting valve (PLV). Australian town water pressure typically runs at around 500 kPa but can spike as high as 1,000 kPa in some areas. Your caravan's plumbing is only rated for around 350 kPa.

The PLV reduces the incoming mains pressure to a safe 350 kPa to protect your hoses, fittings, and taps from damage. Most PLVs also have a built-in non-return valve.

You will usually find the PLV near the front A-frame of your caravan, close to the mains water inlet. On some models, it is located further back on the driver's side behind the rear wheel.

The Most Likely Cause: A Jammed Pressure Limiting Valve

In the vast majority of cases, the problem is a stuck or corroded pressure limiting valve. This is so common that experienced caravan repairers check it first every time.

Why It Gets Stuck

Caravan park taps often spit out grit, sand, sediment, and mineral deposits — especially when first turned on. This debris flows straight into your PLV and over time:

• The brass piston inside becomes discoloured and pitted from corrosion
• Grit lodges between the piston and the barrel, preventing it from sliding
• The spring mechanism jams, blocking water flow entirely or reducing it to a trickle
• Mineral deposits build up and seize the internal components

Once the piston is stuck, the mains water pressure pushes it closed but the spring cannot push it back open. Result: no water gets through.

How to Fix It

Tools you will need:

• Two spanners (1-inch or adjustable shifting spanners work well)
• A bucket or towel to catch water
• White vinegar
• Plumber's grease (not Vaseline — proper silicone-based plumber's grease from the hardware store, around $8–$15)
• Teflon tape

Step-by-step:

1. Turn off the water supply and disconnect the hose from the mains inlet
2. Locate the PLV — follow the pipe from the mains inlet. It is usually a small brass or chrome fitting with threaded ends, mounted to the chassis or A-frame
3. Remove the PLV — undo the clamps holding it to the frame, then unscrew the fittings on each end. Have a bucket ready
4. Disassemble the valve — use the two spanners to unscrew the two halves of the valve body. It is not spring-loaded when you unscrew it, so parts will not fly out
5. Inspect the piston — pull out the brass piston and spring. If the piston is dark, corroded, or has visible grit on it, you have found your problem
6. Clean everything — soak all the components in white vinegar for 15–30 minutes. Vinegar dissolves mineral deposits and removes grime. Rinse with clean water and dry thoroughly
7. Check the O-rings — inspect the rubber O-rings for cracks, hardening, or deformation. Replace them if they look worn (available from plumbing supply stores for a few dollars)
8. Apply plumber's grease — smear a thin layer of silicone plumber's grease on the piston and O-rings. This helps the piston slide freely and provides a better seal
9. Reassemble — put it all back together, wrap the threads with fresh Teflon tape, and refit to the caravan
10. Test — reconnect the hose and turn on the tap. You should have full water flow inside the van

Total cost if you DIY: Under $30 for grease and tape.

When to Replace Instead of Clean

If the piston is heavily pitted, the barrel is scored, or cleaning does not restore smooth movement, replace the entire valve. A new PLV with integrated non-return valve costs around $80–$90 from caravan accessory stores.

Important: When buying a replacement, make sure it includes both the pressure limiter AND the non-return valve. Some cheaper units only have the pressure reducer — without the one-way function, your pump water will escape out the mains outlet when you are running off tank water.

Other Possible Causes

If cleaning or replacing the PLV does not fix the problem, work through these:

Stuck Non-Return Valve (Check Valve)

Separate from the PLV, there is usually a non-return valve on the outlet side of your water pump. This valve stops mains water from pushing back through the pump and into the tank.

If this valve is stuck closed, it can also block mains water flow. Locate it (usually near the pump), remove it, and check that it opens freely when you push through from the correct direction.

Some owners have fixed a stuck check valve by simply tapping it firmly or pushing a small rod gently through from the underside until it clicks open.

Air Lock in the Lines

If the plumbing lines have been drained (for winterising, transport, or after running a tank dry), air can become trapped in the pipes and block water flow.

To clear an air lock:

1. Fill the water tank (even partially)
2. Turn the water pump on
3. Open the tap closest to the pump
4. Let the pump push water through until it runs smoothly with no sputtering
5. Work through each tap in the van, opening them one at a time
6. Once all air is purged, switch back to mains and test

Kinked or Collapsed Hose

Check the hose between the tap and your inlet. A kink — especially where the hose bends around corners or under the van — can completely stop flow. Also check that the hose itself has not deteriorated and collapsed internally. Cheap garden hoses are prone to this.

Use a dedicated drinking-water-safe caravan hose (the white or blue food-grade ones). They are more rigid than garden hoses and less likely to kink or collapse under pressure.

The Park Tap Itself

Before tearing into your plumbing, check the obvious — is the park's tap actually working? Turn it on without the hose connected and check the flow. Some caravan park taps have very low pressure, and older parks can have partially blocked or faulty taps.

Try a different tap or site if possible to rule this out.

Blocked Inlet Filter

Some caravan mains inlets have a small mesh filter screen where the hose connects. Check whether this screen is clogged with sediment or debris. Remove it, clean it, and refit.

How to Prevent This From Happening Again

Install an Inline Water Filter

The single best thing you can do is fit an inline water filter between the park tap and your caravan's mains inlet. A basic sediment filter ($40–$80) catches grit, sand, and debris before it reaches your PLV.

Many experienced travellers consider this essential kit. Replace the filter cartridge regularly — how often depends on the water quality of the parks you visit, but check it every few weeks.

Run the Tap Before Connecting

Before attaching the hose to your van, turn the park tap on and let it run for 10–15 seconds. This flushes out the initial burst of sediment and grit that sits in the tap and pipe.

Service the PLV Annually

Even with a filter, give your pressure limiting valve a clean and grease once a year as part of your regular caravan service. It only takes 15 minutes and prevents the kind of corrosion buildup that causes sudden failures.

Carry a Spare PLV

They are small, cheap (under $90), and if yours fails in the middle of a trip, having a spare means you can swap it out in 10 minutes rather than spending the whole holiday running off the pump.

Quick Diagnosis Flowchart

Summary

In most cases, a caravan that has no water flow on mains but works fine on the pump comes down to a jammed pressure limiting valve. Grit from park taps corrodes and seizes the internal piston over time.

The fix is straightforward — remove the PLV, clean it with vinegar, grease the piston, and reassemble. If it is too far gone, replace it for around $80–$90. Then fit an inline filter to stop it happening again.

It is a 30-minute job that will save you from spending another weekend running off the pump.
